3D 打印机单端玻封 NTC 热敏电阻 10K B3950 耐温 200℃
Single End Glass Sealed NTC Thermistor For 3D Printer 10K B3950 Max 200℃
单端玻封 NTC 热敏电阻，专为 3D 打印机热端测温；玻璃封装耐高温 200℃，引线外层玻纤耐温套管防护；标准参数 10K 阻值、B 值 3950、测温精度 ±1%；引线可按需定制长度，耐温抗氧化，适配高温喷头环境；广泛用于 3D 打印挤出头、热床高温温度采集。
Single-end glass sealed NTC thermistor, specially designed for hot end temperature measurement of 3D printers. Glass encapsulation withstands temperature up to 200℃, wires protected by high temperature resistant fiberglass sleeve. Standard specs: resistance 10K, B-value 3950, temperature tolerance ±1%. Custom wire lengths available, high temperature and oxidation resistant, suitable for high-temperature nozzle environment. Widely used for high temperature temperature detection of 3D printer extruder and hot bed.
Q1. 规格 Spec
这款 3D 打印玻封热敏电阻标准电气参数是什么？
单端玻璃封装，阻值 10K，B 值 3950，测温精度 ±1%，长期耐温最高 200℃。
What are the standard electrical parameters of this glass-sealed thermistor for 3D printers?
Single-end glass encapsulation, resistance 10K, B-value 3950, temperature tolerance ±1%, maximum long-term temperature resistance 200℃.
Q2. 颜色材质 Color & Material
测温芯体、防护套管、引线分别是什么材质颜色？
测温芯体透明玻璃封装；中间黑色绝缘保护段；外层银白色玻纤耐高温套管，内部金属引线。
What material and color for temperature core, protective sleeve and wire?
Temperature measuring core encapsulated by transparent glass; middle black insulating section; outer silver-white high temperature resistant fiberglass sleeve with inner metal wire.
Q3. 引线长度 Wire Length
玻封 3D 打印机 NTC 热敏电阻现货支持哪些线长，可定制吗？
常备标准引线长度 100mm/150mm/200mm/300mm，可定制任意特殊总长。
What stock wire lengths are available for glass sealed NTC thermistor for 3D printers, is customization supported?
Standard stock wire lengths:100mm/150mm/200mm/300mm, any special total length can be customized.
Q4. 用途 Application
单端玻封耐高温 NTC 热敏电阻适配哪些设备，作用是什么？
适配 FDM / 光固化 3D 打印机挤出喷头、加热热床；承受喷头 200℃高温，实时监测热端温度，保障打印恒温稳定，防止堵头、过热故障。
What equipment is the single-end high temperature glass sealed NTC thermistor suitable for, and what is its function?
It fits extruder nozzles and heated hot beds of FDM /resin 3D printers. It can withstand 200℃ high temperature of nozzle, monitor hot end temperature in real time, ensure stable constant temperature during printing, and prevent nozzle clogging and overheating faults.
Q5. 装箱数量 Carton Qty
3D 打印玻封 NTC 热敏电阻标准出口纸箱一箱可装多少个？
标准出口纸箱每箱 15000PCS，线材分捆收纳，玻璃芯体分层隔开，运输避免玻璃碎裂。
How many pieces of glass sealed NTC thermistor for 3D printers can be packed in one standard export carton?
15000 pieces per export carton. All wires are bundled separately, glass cores are layered separated to avoid glass breakage during transportation.
